Key specification for this condensing unit: 220 V, 380 V, cooling capacity customizable. Everything below is reproduced from the factory data sheet. Made by Sanmenxia Tianshun Refrigeration Equipment Co., Ltd. (4 years on the platform, factory-assessed). For a binding price and lead time, send the volume you need and where it ships to.
Key Features of This Condensing Unit
- Voltage: 220 V, 380 V
- Cooling Capacity: customizable
- Refrigerant: R22/R407C/R134a
- Warranty: 1 Year
- Place Of Origin: China
- Application: Industrial Cooling Solutions
Technical Specifications
| Cooling Capacity | customizable |
|---|---|
| Temperature | -20-8c |
| Voltage | 220 V, 380 V |
| Compressor Type | Scroll |
| Refrigerant | R22/R407C/R134a |
| Compressor Brand | Bitzer |
| Core Components | Pressure Vessel, Motor, PLC |
| Warranty | 1 Year |
| Key Selling Points | Eco-Friendly, High-Accuracy, Competitive Price, High Productivity, Low Maintenance Cost |
| Video Outgoing-Inspection | Provided |
| Place Of Origin | China |
| Weight (Kg) | 200 |
| Type | scroll unit |
| Machinery Test Report | Provided |
| Product Name | Air Cooled Scroll Chiller |
| Function | Cooling alone or cooling and heating |
| Compressor | Scroll Compresor |
| Application | Industrial Cooling Solutions |
| Keyword | High efficiency/corrosion resistance/Cold Room Refrigerant |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
| Condensing Unit Model No. | LFFG-40 | LFFG-50 | LFFG-70 | LFFG-90 | LFFG-100 | ||
| Applicable Temperature | -5℃~8℃ | ||||||
| Refrigerant | R22 | ||||||
| Power Supply | 380V/50HZ | ||||||
| Compressor | Type | Semi-hermetic Screw Type | |||||
| Model | FVRH-40-120 | FVRH-50-140 | FVRH-70-200 | FVRH-90-270 | FVRH-100-300 | ||
| Energy adjustment | 75%-100% | 50%-75%-100% | |||||
| Compresor cooling capacity and power | 0℃Evaporative Temperature | (W) | 104.2 | 136.8 | 199.3 | 271.7 | 294.1 |
| Cooling capacity | |||||||
| (KW) | 32.9 | 41.2 | 60 | 78.2 | 85.3 | ||
| Power | |||||||
| -5℃Evaporative Temperature | (W) | 85.7 | 112.5 | 164 | 223.6 | 242 | |
| Cooling capacity | |||||||
| (KW) | 31.5 | 39.5 | 57.5 | 74.9 | 81.7 | ||
| Power | |||||||
| -10℃Evaporative Temperature | (W) | 69.8 | 91.8 | 133.7 | 182.5 | 197.5 | |
| Cooling capacity | |||||||
| (KW) | 30.2 | 37.8 | 55 | 71.8 | 78.3 | ||
| Power | |||||||
| Joint | (diameter:mm) | 54 | 66 | 76 | 108 | 108 | |
| Suction joint | |||||||
| (diameter:mm) | 28 | 35 | 35 | 42 | 42 | ||
| Liquid Outlet Joint | |||||||
| (diameter:mm) | 42 | 42 | 54 | 66 | 66 | ||
| Suction joint | |||||||
| (diameter:mm) | 35 | 35 | 35 | 54 | 54 | ||
| Liquid Inlet Joint | |||||||
| Shape Size | A(mm) | 1700 | 2150 | 2300 | 2600 | 2600 | |
| B(mm) | 670 | 680 | 770 | 850 | 850 | ||
| C(mm) | 1100 | 1100 | 1250 | 1300 | 1300 | ||
Ordering and Pricing
- Minimum order quantity: 1 set
- Volume pricing:
- 1–4 set: US $3580 / set
- 5–9 set: US $1890 / set
- 10+ set: US $1688 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this condensing unit?
The standard minimum order quantity is 1 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Can the condensing unit be supplied for my local voltage?
The standard configuration is 220 V, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
About the Manufacturer
This product is produced by Sanmenxia Tianshun Refrigeration Equipment Co., Ltd., based in China. The company 4 years as a verified Alibaba.com supplier, operates its own manufacturing, passed third-party supplier assessment. Browse the full Sanmenxia Tianshun Refrigeration Equipment Co., Ltd. range on HVACR Nexus.
