Yellow explosion proof ventilator — voltage 110, 220, 380 V, power source Electric. The complete factory specification follows. Made by Foshan Nuowei Ventilation Co., Ltd. (8 years on the platform, typical reply ≤3h). Send your target quantity and destination for a firm quotation with current lead times.
Key Features of This Yellow Explosion Proof Ventilator
- Model Number: NW-BTF
- Power Source: Electric
- Power Supply: 300 ~ 3000 W
- Voltage: 110, 220, 380 V
- Blade Material: Cast Iron
- Material: Iron with spray paint
Technical Specifications
| Voltage | 110, 220, 380 V |
|---|---|
| Type | Duct Axial Fan |
| Blade Material | Cast Iron |
| Mounting Type | Duct Fan |
| Bearing Type | Sleeve Bearing |
| Power Source | Electric |
| Warranty | 1 Year |
| After-Sales Service Provided | Online support |
| Place Of Origin | Guangdong, China |
| Brand Name | Nuo En Wei |
| Model Number | NW-BTF |
| Product Name | Portable Axial Flow explosion proof fan |
| Material | Iron with spray paint |
| Dimension | Dia 250,300,400,450500,600,700,800 mm |
| Motor | 100% copper coil motor |
| Color | Red, yellow |
| Certificate | CE |
| Speed | 2800r/min |
| Power Supply | 300 ~ 3000 W |
| Noise | 66 ~ 81 dB |
| Selling Units | Single item |
| Single Volume | 0 cm³ |
| Single Gross Weight | 0.0 kg |
Product Details
VR
200mm-400mm yellow Color Explosion Proof Ventilator Low Noise Portable ventilation Fan
Products Description
Specification
explosion-proof ventilation Fan
Detailed Product Description :
-Single Phase Two Pole Explosive Proof Low noise and Light weight due to die-casting aluminum alloy Features of the blower : by explosion-proof electric motor, explosion-proof switch,cast aluminum fan, copper inner barrel components. Application : 1.Paint warehouse , painting ,dry paint , gas tank , duct space-Working sewer and cable 2.Blowing bad gas when welding shipbuilding, canning, bridge,chemical lab, depot , mining , oil field 3.Good insulation performance, convenient to move. Widely usedin ships, flammable and explosive gas stations and other places.effectively prevent the fan start, operation, close of the electricalspark,ensure the use of safety!
Technical Parameters | ||||||||||||||
Spec | Voltage | Freguency | Power | Speed | Capacity | Static Pressure | Noise | |||||||
mm | V | Hz | W | r/min | m³/min | Pa | dB(A) | |||||||
200 | 220 | 50/60 | 150/230 | 2800 | 25/30 | 245/294 | 61 | |||||||
200 | 110 | 50/60 | 150/230 | 2800 | 25/30 | 245/294 | 61 | |||||||
300 | 220 | 50/60 | 550/620 | 2800 | 65/77 | 373/440 | 71 | |||||||
300 | 110 | 50/60 | 520/620 | 2800 | 65/77 | 373/440 | 71 | |||||||
Production Process
Our products are widely used in airport boarding bridges, shipbuilding, furniture manufacturing, municipal engineering,underground project, tunnel construction, fire smoke, and so on.
Our products have passed the ISO 9001, SGS, UL94,CE certification authority, and have been exported to the United States
(USA),Germany, Japan, Europe, Australia, Hong Kong, Taiwan, etc. 180 countries and regions.
Company Profile
ABOUT US
Foshan NuoWei Ventilation Co., Ltd. is a professional R&D, manufacturing, and global sales one of the ventilation duct with a portable fan manufacturing enterprise, the factory has more than ten years of experience in the technical team and advanced production equipment and technology.NuoWei insists on the pursuit of excellent quality, as the industry's leading ventilation equipment specialist manufacturer providing quality products and services to customers in 180 countries and regions worldwide, the company adheres to the quality survival, quality, and development, to the business philosophy of quality and efficiency, and many enterprises established long-term stable cooperative relations, and obtain the unanimous recognition and praise of our customers at home and abroad.
NuoWei With advanced manufacturing equipment and a strong technical team, for domestic and foreign to provide Marine ventilation hoses, tunnel ducts, airport boarding corridor blower hoses, underground ventilation hoses, air conditioning insulation flexible hoses,anti-static(conductive) ducts, high-temperature flexible duct, abnormal shape hose, portable fan, portable explosion proof fan,36V marine low-pressure fan, portable plastic fans, and other quality products.
The products are widely used in mining, shipbuilding, furniture manufacturing, municipal engineering, airport boarding
bridges,laboratory and underground engineering, fire smoke, and tunnel construction. the products have been exported to the United States, Germany, Japan, Europe, Australia, Hong Kong, Taiwan regions etc. Welcome at home and abroad to visit our factory for business negotiation.NouWei will provide you with high-quality products. we believe that future success belongs to quality leaders in the century.
Our Advantages
1. Factory Direct Sale: Nuowei is a factory based in Guangdong, China.
2. 10+ years experience: We are a professional company in this ventilation duct.
3. Small MOQ: small MOQ to meet different customers requirements.
4. Fast response: response to you in 24 hours, and take quick action in production.
5. High quality assurance: ISO9001 quality control system, CE/ SGS certificates as the proof.
6. Delivery time: after receiving confirmation of order.
7. Quality guarantee: All products are 100% QC inspection before shipment.
8. OEM or ODM is warmly welcome.
2. 10+ years experience: We are a professional company in this ventilation duct.
3. Small MOQ: small MOQ to meet different customers requirements.
4. Fast response: response to you in 24 hours, and take quick action in production.
5. High quality assurance: ISO9001 quality control system, CE/ SGS certificates as the proof.
6. Delivery time: after receiving confirmation of order.
7. Quality guarantee: All products are 100% QC inspection before shipment.
8. OEM or ODM is warmly welcome.
Product packaging
PAYMENT
We usually use TT.
T/T 30% deposit before production and balance 70% before delivery or against B/L copy if see shipment.
100%L/C at sight.
Westunion, paypal is available.
SHIPPING
If the quantity of order is not very big,we could send them to you by express delivery,such as TNT,DHL,UPS OR EMS etc.
If order is big ,we will advise you use Air Shipping or Sea Shipping through your nominated forwarder agent.Our long-term
cooperated agent also available.
Freight collect if bulk shipment.
Delivery Time:Please check with us before placing order
We usually use TT.
T/T 30% deposit before production and balance 70% before delivery or against B/L copy if see shipment.
100%L/C at sight.
Westunion, paypal is available.
SHIPPING
If the quantity of order is not very big,we could send them to you by express delivery,such as TNT,DHL,UPS OR EMS etc.
If order is big ,we will advise you use Air Shipping or Sea Shipping through your nominated forwarder agent.Our long-term
cooperated agent also available.
Freight collect if bulk shipment.
Delivery Time:Please check with us before placing order
FAQ
Q1. When can I get the quotation?
A1.We usually quote the prices within one workday (24 hours) upon receiving inquiry. But if you need urgent quotation, you can send message to the trade manager and communicate with us on line, or make a phone call directly.
Q2. How can I get a sample to check your quality?
A2. Once the price are confirmed OK by your side, you can require us to provide sample for checking quality.
Q3. Can you make the customized goods?
A3. Yes, we can make it according to your requirement, such as material, thickness, diameter, length, accessories, etc.
Q4. What is the MOQ of your products?
A4. Different products have different MOQ requirement. Certainly sample orders are available for all goods.
Q5. How about your delivery time?
A5. The delivery time depends on the order quantity, stock material quantity, and other factors.
Q6. How about your after-sales service?
A6. We can provide 24 hours on line after-sales service to help customers solve their problem.
A1.We usually quote the prices within one workday (24 hours) upon receiving inquiry. But if you need urgent quotation, you can send message to the trade manager and communicate with us on line, or make a phone call directly.
Q2. How can I get a sample to check your quality?
A2. Once the price are confirmed OK by your side, you can require us to provide sample for checking quality.
Q3. Can you make the customized goods?
A3. Yes, we can make it according to your requirement, such as material, thickness, diameter, length, accessories, etc.
Q4. What is the MOQ of your products?
A4. Different products have different MOQ requirement. Certainly sample orders are available for all goods.
Q5. How about your delivery time?
A5. The delivery time depends on the order quantity, stock material quantity, and other factors.
Q6. How about your after-sales service?
A6. We can provide 24 hours on line after-sales service to help customers solve their problem.
Ordering and Pricing
- Minimum order quantity: 2 set
- Volume pricing:
- 2+ set: US $260 / set
- Ships from: China
- Customization: OEM and ODM accepted on qualifying volumes.
Frequently Asked Questions
What is the minimum order quantity for this yellow explosion proof ventilator?
The standard minimum order quantity is 2 set. Trial orders can usually be arranged for buyers evaluating the product before a full production run.
What warranty is provided?
The manufacturer provides a 1 Year warranty. Spare parts and technical support remain available after the warranty period.
Which certifications does this yellow explosion proof ventilator carry?
It is supplied with CE documentation, which covers the requirements of most import markets. Additional test reports can be issued on request.
Can the yellow explosion proof ventilator be supplied for my local voltage?
The standard configuration is 110, 220, 380 V. Alternative voltage and frequency builds are available when specified at the time of order.
Do you accept OEM or custom branding?
Yes. Custom logo, colour, packaging and specification changes are accepted on qualifying order volumes. Send your artwork and technical requirements with your enquiry.
How long does production and delivery take?
In-stock configurations typically ship within 7–15 days. Customised or large-volume orders are usually produced in 25–35 days, confirmed on order.
